Applications
For water supply from wells or reservoirs.
For domestic use, for civil and industrial applications.
For garden use and irrigation.
Operating conditions
Maximum fluid temperature up to +50°C
Maximum sand content:0.25%
Maximum immersion:80M
Minimum well diameter:4"
Motor and Pump
Rewindable motor or Full obturated screen motor
Three-phase:380V-415V/50HZ
Single-phase:220V-240V/50HZ
Equip with start control box or digtial auto-control box
Pumps are designed by casing stressed
NEMA dimension standards
Curve tolerance according to ISO2548
Options on request
Special mechanical seal
Other voltages or frequency 60HZ
Warranty:1 year
(according to our general sales conditions).
PERFORNANCE DATA 50HZ
| MODEL | P2 | DELIVERY n=2850 r/min | |||||||||||||
| 1~ 220V/240V | 3~ 380V/415V | KW | HP | Q | m³/h | 0 | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 2.7 |
| l/min | 0 | 5 | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 45 | |||||
| 4SP2/55 | 3 | 4 | H(m) | 326 | 317 | 307 | 295 | 280 | 260 | 232 | 194 | 146 | 85 | ||
Q1. What's your company's main products?
A: Our company is specialized in pumps, fans, motors, air compressors, electric welders and so on.
Q2. What's your payment term?
A: 30% T/T in advance, the rest pay off before delivery.
Q3. What's the MOQ for your production?
A: The MOQ is 100pcs or depends on your requirements.
Q4. Is it all right to make customer's own brand name?
A: OEM is ok.
Q5. Where is your loading port?
A: Ningbo, or else port in China as your requirements.
Q6. Are you a manufacturer or trading company?
A: We are a manufacturer.
